The mouth of the elliptical head is still circular, but its cross section is elliptical. The elliptical heads we often use are those with a ratio of 2:1.

They are divided into EHA heads based on the inner diameter and EHB heads based on the outer diameter, which are collectively called elliptical heads.

The elliptical head is a type of heating furnace component in a high-pressure container. The medium-frequency induction heating method is used to heat

the water pipe partially and the gear transmission is used to bend the elbow. The output power can reach 120KW. It can heat water pipes of various sizes and specifications.

It heats quickly, the output power can be infinitely adjusted, the starting characteristics are good, the characteristics are stable,

the space is small, and it is easy to operate and maintain. The elliptical head is a component of the container. According to the different geometric shapes,

it can be divided into spherical, elliptical, dish-shaped, spherical crown, cone shell friendly cover and other categories. Among them, the spherical, elliptical,

dish-shaped, and spherical crown elliptical heads are also commonly called convex elliptical heads. It is used in various container equipment, such as storage tanks,

heat exchangers, towers, reactors, heating furnaces and separation equipment.

The elliptical head is a head composed of a rotating elliptical sphere and a cylindrical straight section. If the pipe is not going to be extended at the end, the elliptical head can be welded to the pipe and used as an end. Or it can be used on a pressure vessel, with a head on the top and bottom, and a straight pipe section in the middle, as a tank for the pressure vessel.

The deformation of the elliptical head is caused by the inconsistency between the large piece of the disc and the actual thickness of the joint itself, the uneven punching force or the uneven heat and cold during heat treatment. Solution: The principle of thermal expansion and contraction can be used to heat the deformed head, and then quickly cool it with water, or it can be corrected by spinning.

The scratches on the elliptical head are mainly caused by improper operation during transportation. For example: hook scratches, forklift scratches. Solution: First, pad the protective film on the contact surface between the hook and forklift and the head. After scratches, polish them, and perform repair welding for severe ones. If the scratch area exceeds 25%, it must be treated as a whole.

How to increase the thinning rate of the elliptical head? The uniform thickness of the formed head can avoid stress concentration and increase the service life of the head. The processing allowance is determined according to the manufacturing process to ensure that the thickness of the convex head and the hot roll section after forming is not less than the nominal thickness of the component minus the negative deviation of the steel plate.

Most of the orange peel phenomenon of the elliptical head is due to the stratification of the plate itself, but it cannot be observed by the naked eye. The orange peel phenomenon can only be discovered during the stamping and drum pressing process. Solution: The relatively shallow orange peel phenomenon can be cleaned by fine grinding. The deeper one needs to be repaired by welding and then polished.
